AO3422

Alpha & Omega Semiconductor (AOS) AO3422 (power MOSFET (N-channel)) is designed for motor drive, power conversion and power amplification requiring high voltage and high current. Genuine stock; Rds(on), Vceo and package thermal performance per the official datasheet. Contact us for volume pricing and stock.

New & Original Prototype to volume sourcing
COMPONENT PROFILE
AOS AO3422
Image for reference
Package
SOT-23

Product overview

Alpha & Omega Semiconductor (AOS) AO3422 (power MOSFET (N-channel)) is designed for motor drive, power conversion and power amplification requiring high voltage and high current. Genuine stock; Rds(on), Vceo and package thermal performance per the official datasheet. Contact us for volume pricing and stock.

Manufacturer
AOS
Part number
AO3422
Category
Power MOSFETs (N-Channel)
Package
SOT-23
Packaging
Reel
Condition
New & Original
Lifecycle
Confirm with manufacturer
Lead time / MOQ
Confirm with quotation

Technical parameters

32 parameters

Construction

Continuous Drain TA=25°C
2.1
Power Dissipation TA=70°C
0.8
Maximum Junction-to-Ambient A t ≤ 10s
75 °C/W
Maximum Junction-to-Ambient A Steady-State
115 °C/W
Maximum Junction-to-Lead C Steady-State RqJL
48 °C/W
VDS=44V, VGS=0V
1
VGS=4.5V, ID=2.1A
125
VGS=2.5V, ID=1.5A
157 mW
gFS Forward Transconductance VDS=5V, ID=2.1A
11 S
Ciss Input Capacitance
214 pF
Coss Output Capacitance VGS=0V, VDS=25V, f=1MHz
31 pF
Crss Reverse Transfer Capacitance
12.6 pF
Qg Total Gate Charge
2.6 nC
Qgs Gate Source Charge VGS=4.5V, VDS=27.5V, ID=2.1A
0.6 nC
Qgd Gate Drain Charge
0.8 nC
tD(on) Turn-On DelayTime
2.3 ns
tr Turn-On Rise Time VGS=10V, VDS=27.5V, RL=12W
2.4 ns
tD(off) Turn-Off DelayTime RGEN=3W
16.5 ns
tf Turn-Off Fall Time
2 ns
trr Body Diode Reverse Recovery Time IF=2.1A, dI/dt=100A/ms
20 ns

Performance

Drain-Source Voltage
55 V
Gate-Source Voltage
±12 V
Current A TA=70°C
1.7 A
Junction and Storage Temperature Range TJ
55 to 150 °C
BVDSS Drain-Source Breakdown Voltage ID=10mA, VGS=0V
55 V
IGSS Gate-Source leakage current VDS=0V, VGS=±12V
100 nA
VGS(th) Gate Threshold Voltage VDS=VGS ID=250mA
1.3 V
ID(ON) On state drain current VGS=4.5V, VDS=5V
10 A
RDS(ON) Static Drain-Source On-Resistance TJ=125°C
175
VSD Diode Forward Voltage IS=1A
0.78 V
IS Maximum Body-Diode Continuous Current
1 A
Rg Gate resistance VGS=0V, VDS=0V, f=1MHz
1.3 W

Specifications & documentation

Use the official manufacturer documentation to verify electrical characteristics, package dimensions and operating limits before design approval.

Request confirmation of current stock, date code, packaging, price and delivery terms. Product information does not constitute a binding offer; final specifications are confirmed with your quotation.
